Main features:

• Exceptional signature repeatability
• Optimal towing depth
• Non-wearing electrodes
• Adjustable depth
• Stainless steel frame

Marine sparkers are among most widely used high and ultra-high resolution seismic sources for reflection marine seismic surveys.

Modern sparkers are used for all types of engineering and scientific applications and operate in wide range of water depth – from first meters up to several kilometers, providing detailed, high-resolution images of subsurface.

GEODEVICE designs and produces full range of marine sparkers: starting from lightweight SWS-250 for shallow engineering purposes up to powerfull SWS-2500 for oceanology studies.

All our sparkers support industry standard 2D and 3D acquisition techniques and ensure succesfull long-term in-field operations due to:

• Exceptional signature repeatability
• Optimal towing depth with it’s easy adjustment if required
• Non-wearing electrodes due to negative discharge technology of MultiJack Energy Source
• Specific tip arrangement for optimal signal generation
• GPS installment tool for high-precision positioning

Review some of our most popular modifications:

SWS-500

• Applicable for 2D/3D surveys
• Vertical resolution up to 10 cm
• Operational depth range – 3 m to 1500 m
• Penetration up to 500 m below the seabed
• Applications:
  • Geohazard assessment
  • Renewable installations
  • Engineering surveys
  • Mineral explorations
  • Stratigraphic studies

Data examples:
